| Arm Style | Half crank |
| Boring Pattern | 45 mm |
| Cabinet Type | Face-frame,Frameless |
| Color/Finish | Nickel |
| Cup Depth(mm) | 11 mm |
| Cup Diameter (mm) | 35 mm |
| Height Adjustment (mm) | +/- 2 mm |
| Manufacturer Series | Series 200 |
| Material Type | ST || Steel || Steel |
| Motion Technology | Self-close |
| Mount Type | Dowel |
| Opening Angle | 165 Degree |
| Overlay (in) | Half overlay |
| Side Adjustment | + 4.5 mm/- 1.5 mm |
