• Soft close system with adapting damping
• Full extension with synchronization travel
• Maximum drawer box material thickness: 5/8" (16 mm)
• Minimum inside drawer width: 8-5/32" (207 mm)
• 66 lb (30 kg) dynamic load capacity
• Exceeds ANSI/BHMA A156.9-2010 technical specifications
• 2D (4-way) micro roller adjustable, height (up and down), horizontal (side-to-side)
• Smart Lock front locking devices sold separately
• Depth adjustment achieved by elongated holes in slide
• Tool-less installation
Packing & Sold: 6 pairs per box. Full box quantities only.
| Cabinet Type |
Face-Frame |
| Color/Finish |
Zinc |
| Extension |
Full extension |
| Material Type |
St |
| Motion Technology |
Soft-Close |
| Size |
15" |
| Weight Capacity |
66 lb |
