• Tool-less, intuitive adjustment of the drawer front panel: Height adjustment up to +3mm, Side adjustment up to +/-1.5mm (max. drawer side profile thickness 15mm), Depth adjustment up to +2mm/-1mm, Tilt adjustment up to +4 mm and radial adjustment up to +/-1.5mm
• Integrated Silent System
• Load capacity up to 30 kg for standard applications; Version available for particularly light drawers up to 10 kg
• Optional can be retrofitted with Push to open Silent: convenient opening mechanism in combination with silent and soft closing; can be retrofitted with synchronisation
• Slide on installation with 2D front fixing clips and tilt adjustment
• Load capacity to EN 15338, Level 3
• Galvanised steel
| Bearing Type |
Ball Bearing |
| Cabinet Type |
Face-Frame,Frameless |
| Color/Finish |
Zinc |
| Extension |
Full extension |
| Material Type |
St |
| Motion Technology |
Soft-Close |
| Orientation |
Right Hand |
| Size |
18" |
