Blum

COMPACT BLUMOTION 39C hinges for full overlay | Cup Mount: Press-in, Overlay: 1" | 39C358B16

Item # / SKU: 39C358B16 MPN: 39C358B16 Brand: Blum
Fast Shipping Direct from our distribution centers
Expert Support Dedicated account representatives
Quality Guaranteed Trusted brands, professional grade
- BLUMOTION soft close integrated into the hinge cup - 45 mm boring pattern - Dowel hinges must be inserted with knock-in tool or COMPACT insertion ram - One-piece wraparound hinge - +/- 3/32", - 1/32" cam depth adjustment - +/- 1/8" height adjustment - +/-1/16" side adjustment - Deactivation switch for small/light doors - Overload safety feature - 1/2" cup depth
Boring Pattern 45 mm
Cabinet Type Face-Frame
Color/Finish Nickel
Cup Depth 13 mm
Cup Diameter 35 mm
Cup Mount Press-In
Depth Adjustment + 3/32 in / -1/32 in
Height Adjustment +/- 1/8 in
Material Type St
Motion Technology Soft-Close
Mount Type Dowel
Opening Angle 110 Degree
Overlay 1"
Pack Quantity 300
Position Wraparound
Side Adjustment +/- 1/16 in
Size 1" OL

No documents are currently available for this product.

Contact us at webteam@wurthwoodgroup.com for technical documentation.
