| Arm Style | Straight |
| Boring Pattern | 45 mm |
| Cabinet Type | Face-Frame,Frameless |
| Color/Finish | Nickel |
| Cup Depth | 13 mm |
| Cup Diameter | 35 mm |
| Depth Adjustment | + 3 mm/- 2 mm |
| Height Adjustment | +/- 2 mm |
| Material Type | St |
| Motion Technology | Self-Close |
| Mount Type | Dowel |
| Opening Angle | 170 Degree |
| Overlay | Full Overlay |
| Pack Quantity | 125 |
| Side Adjustment | +/- 2 mm |
| Size | 170 DEGREE |
No documents are currently available for this product.
Contact us at webteam@wurthwoodgroup.com for technical documentation.
