• For 5/8" (16 mm) max. drawer side thickness
• Drawer height adjustment -0, +3mm
• 75 lbs dynamic load cap, 100 lbs static
• BIFMA, KCMA. BHMA rated & app; tested to over 50,000 cycles
• Roller allows for smooth, quiet operation & reduces deflection when extended
• Soft-close mechanism, activated at 2 inches
• Front clip has a 3 screw mounting design to allow attachment to front and side of drawer
• 6pr/box, slides, front clips and rear sockets included
Pricing breaks are at the following quantities: 1-29, 30-59 and 60+
